Scales M-ER 221 F-32.5
-
$713
- In Stock
- Product Code: 543404836
Specifications Manufacturer: MERCURY-EQUIPMENT Country: China Warranty period: 6 months. Article: 3141 Scales M-ER 221 F-32.5 "Install" RS-232 Model M-ER 221 F Install is one of the thinnest built-in electronic scales on the market. They are built into cash desks or tables. This model can also be used as a separate device. Weighing range: from 100 grams to 32 kilograms. Design features The body is made of reliable metal. The platform is made of food grade stainless steel. Body dimensions: 330 * 320 * 80 in. Platform area: 330 * 320 in. The load cell is OIML certified. On the side panel there is an LED display, zero and tare buttons. These elements duplicate the software functionality of the scales. Since the scales are built-in, the main functionality is embedded at the software level. The kit may include (upon request): Built-in battery. RS-232 to USB adapter. The M-ER 221 F Install scales have several connection interfaces. RS-232 or USB interface can be used to connect to the POS system. Electronics and software The scales are synchronized with the computer via the CAS-M and POS-2M protocols. The device supports the 1C system and most online cash registers. Drivers for synchronization can be downloaded for free from the manufacturer's website. Upon request, the design can implement the following protocols: Massa-K. POS-2. The device can be synchronized with OPOS and JavaPos. The electronics are compatible with Windows and Linux. Old versions of Windows are supported: 7, 8, XP. To work with these operating systems, you need a virtual COM port driver. It can be found on the manufacturer's website in the "Download" tab. A driver is not required to work with Windows 10. Connection to Linux is carried out via cdc_acm. This is a standard module that is automatically loaded when connecting the scale to Ubuntu. Technical parameters: Scale type: Packing Maximum weight: 32 kg Resolution: 5 g Design: Built-in Minimum weight: 100 g Platform size: 330*320 in Verification: Yes Accuracy class: Medium (III) Load cells, pcs: 1 Functionality: Operating modes: Simple weighing; Weight recording; Selection of units of measurement; Accounting for tare weight Tare sampling range: Entire range Units of measurement: Gr; kg Visual indication: Yes Self-diagnostic mode: Yes Level: Yes Operating parameters: Power supply 9V - 0.5A Permissible humidity: 85% Atmospheric pressure: 630...800 in Hg Operating temperature: 0°C ~ +40°C Display: Number of display digits 4 Interfaces: RS-232 Case: Overall dimensions (WxLxH), in 330*320*80 Platform material: Metal Case material: Metal Weight: 5.3 kg Overload protection: Sound and visual alert Corrosion protection: Galvanization Adjustable supports: Yes
| Main | |
| Warranty period | 6 months |
| Manufacturer | MERCURY-EQUIPMENT |
| Country | China |
