Thermal proofing cabinet Abat ШРТ 10-1/1М, 10 levels GN 1/1, manual control, temp. +20…+85°С, full stainless steel, 840x730x980mm, 2.53kW, 230V Thermal proofing cabinet Abat ШРТ 10-1/1М is used in bakeries, canteens and cafes for preliminary processing of bakery products and their preparation for baking. Such processing is called proofing and consists of temporary stay of formed blanks in a warm environment. Proofing of dough products in the chamber of thermal proofing cabinet Abat ШРТ 10-1/1М will increase the volume of each blank. During proofing, the dough is enriched with carbon monoxide (carbon dioxide), which gives it porosity and fluffiness. The proofing cabinet can also be used to defrost meat, fish or vegetable semi-finished products. The design of the Abat proofing thermal cabinet ШРТ 10-1/1М consists of a box-shaped body, a working chamber, a water bath, a control panel, a door and legs with adjustable height. The working chamber of the proofing cabinet is equipped with ten rows of guides for placing baking sheets or GN 1/1 gastronorm containers. The presence of space for ten levels allows for the rapid processing of a large number of dough blanks. The operating principle of the Abat proofing cabinet ШРТ 10-1/1М is simple. The air is heated using heating elements. The air can be heated from 20 to 85°С. Using the thermostat knob, the operator can set the appropriate temperature. Proofing is usually carried out at a temperature of 40 to 45°С. The proofing cabinet of this model is equipped with fans, the rotation of which allows distributing heated air across all ten levels of the chamber and uniformly heating each workpiece. Maintaining the optimal level of humidity is ensured by water baths. The door of the Abat proofing cabinet ШРТ 10-1/1М is equipped with glass resistant to high temperatures. Two lighting lamps are built into the chamber, providing good visibility and allowing you to monitor the proofing process. The chamber and the body of the proofing cabinet are made of stainless steel. The Abat ШРТ 10-1/1М thermal proofing cabinet is designed for a long service life. Additional technical characteristics: Current type: single-phase, alternating Current frequency: 50 Hz Nominal power of heating elements: 2.4 kW Nominal power of lighting lamps: 2x0.05=0.1 kW Nominal power of the fan: 0.03 kW Number of heating elements: 2 pcs. Number of thermostats: 1 pc. Power consumption to maintain a temperature of 40°C: 0.6 kW/h Air temperature control range in the working chamber: from 20 to 85°C Operating temperature on the shelves when the thermostat is set to 40°C: 40±5°C Time to heat up the chamber to an operating temperature of 40°C: 20 min. Volume of water poured into the bath: 3 l Humidity level in the chamber: from 50 to 95% Total combined illumination in the chamber: 150 lux Maximum number of installed GN 1/1 gastronorm containers: 10 pcs.
