Specifications Manufacturer: IRTYSH Country: RUSSIA Article: PVT - 2Df 1 Rotary oven IRTYSH PVT - 2Df1 (2650x1620x2480mm; 51 kW; for 600x800mm baking sheets; stainless steel body) Oven with a rotating trolley PVT-2D made of stainless steel with software control is designed for baking a wide range of bakery products at retail, catering and bakery enterprises. Allows you to bake the entire range of bakery products, including rye-wheat varieties, sliced ​​loaves and small-piece products, as well as any confectionery (cakes, pastries, gingerbread, etc.). Distinctive features: Original design solutions and modern design of the PVT-2D oven put it in line with similar imported products. The control panel is a separate unit consisting of a frame structure with two door leaves. The front door is for servicing the control unit. The side door is for servicing the power electrical part. The power element part is made of a reliable element base of the IEK company with a warranty period of 3 years. The bottom of the baking chamber is aligned with the rotating disk of the cradle to facilitate rolling the trolley with products into the oven. The design maximally excludes the ingress of debris into the cradle support unit, which prolongs the service life of the support. The cradle frame is reinforced, namely, it is made of a rectangular pipe 50 x 25 in. The trolley design is more rigid, made of a rectangular pipe 25 x 25 in. Shelves for fixing forms, pallets, etc. are made of more durable material. A button for turning the oven cradle is introduced on the control panel. The oven design includes an automatic lifting of the trolley threshold, mechanically connected to the opening (closing) of the door, which reduces the time for bringing in (taking out) the trolley and, as a result, reduces heat (electricity) losses. Opening the oven door by 105º increases convenience during operation. The glass is sealed with a rubber U-shaped profile, which makes the design more airtight. The door design has a solid glass. Flexible adjustment of baking modes (the ability to set parameters for up to 10 different temperature values ​​and up to 5 steam humidification intervals, automatically maintained during the program cycle). Extended system of locks and diagnostics with fault indication on the control panel: Door lock; Oven overheating; Trolley rotation drive failure; Fan rotation drive failure; Thermocouple break; The oven emergency state is accompanied by an audible alarm. The "HEATING" function; - automatically brings the oven to the operating mode at the temperature of the set program, and will maintain it until the "START" button is pressed to perform the set baking program. "ADDITIONAL TIME" function - automatically bakes products for 5 minutes at the final temperature of the cycle of the selected program.This operation can be performed several times, which is very convenient when practicing baking technology. Uniformity of baking due to uniform heat supply over the entire surface of baked products due to forced circulation of hot air using two recirculation fans. Convenient adjustment of ventilation slots allows, in comparison with other equipment of this class, to provide the best uniformity of baking of bakery products due to the most favorable distribution of heat over the entire surface of baked products. Efficient formation of steam is achieved by a steam generator, which has a large evaporation area, and the release of a large amount of steam in a short period of time. The presence of heat removal after baking ensures safety in operation. Availability of a steam removal and ventilation system of the baking chamber. Specifications: Number of heating elements in the oven, pcs. 12 Nominal power, kW 51 Power supply voltage, V 400 Productivity, kg/h 150 Total power of heating elements, kW 48 Automatic temperature maintenance range, ºС 30-290 Trolley rotation speed, rpm no more than 6 Nominal fan power, kW 0.55 Number of fans, pcs. 2 Nominal power of trolley rotation drive, kW 0.25 Number of programs 100 Number of possible intermediate temperature setting points, pcs. 10 Number of possible intermediate humidification setting points, pcs. 5 Overall dimensions, in 2500 x 1604 x 2870 Weight, no more than, kg. 165016501650
